MP-431D1 Wired adapter for interfacing with third party systems and equipment
Price: 5 660.00 RUB.
Description
The MP-431D1 wired digital adapter for interfacing with external life support systems is designed to work as part of various personnel call systems (hospital systems, personnel call systems for the disabled, etc.) and serves to send a call to the MP-331W1 tent console from any other medical device.
Technical specifications:
| Supply voltage, V | ±12 ±10% |
| Maximum current consumption, mA | 1 |
| Button number range | from 1 to 9 |
| Mode of operation | around the clock |
| Operating temperature range, °C | +5÷45 |
| Relative humidity, % | no more than 80 |
| Atmospheric pressure, mmHg | from 650 to 800 |
| Constructive | wall mounted overhead mount |
| Dimensions, mm | 82х82х18 |
| Weight, g | 150 |
| Service life | at least 5 years |
3D View
